# + [markdown] id="odZq7fqcnuq1"
# Lecture 3: Digital Audio Signals
#
# Audio Processing, MED4, Aalborg University, 2021
#
# By <NAME> (<EMAIL>) and <NAME> (<EMAIL>)

# + [markdown] id="2jp4jNyUnuq7"
# Central aspects of the course
# - [x] What is sound?
# - [x] How is sound generated?
# - [ ] **How is sound turned into signals (i.e., data) on a computer?**
# - [ ] How can we analyse these signals (i.e. extract information from them)?
# - [ ] How can we modify these signals?
# <center>
# <img src="https://github.com/SMC-AAU-CPH/med4-ap-jupyter/blob/main/lecture3_Digital_Audio_Signals/figures/apOverview.png?raw=1" alt="Course overview" width="100%"/>
# </center>
#

# + [markdown] id="lY1Vkhjynuq9"
# # Sampling and reconstruction
# In the next 20 minutes, you will learn
# - What a **continuous-time** signal is.
# - What a **discrete-time** signal is.
# - How you turn a continuous-time signal into a discrete-time signal (i.e., **sampling**).
# - How you turn a discrete-time signal into a continuous-time signal (i.e., **reconstruction**).

# + [markdown] id="MHi5YpbNnuq9"
# In the figure below, the following is happening:
# 1. An audio signal $p_\text{i}(t)$ is propagating through the air as **pressure variations**.
# 2. The microphone picks up the pressure variations and turns them into **voltage variations** $v_\text{i}(t)$.
# 3. The voltage is converted into a series of numbers $x_n$ via **sampling**.
# 4. A voltage signal $v_\text{o}(t)$ is **reconstructed** from the series of numbers $x_n$.
# 5. A loudspeaker converts the voltage variations into pressure variations $p_\text{o}(t)$.
#
# <center>
# <img src="https://github.com/SMC-AAU-CPH/med4-ap-jupyter/blob/main/lecture3_Digital_Audio_Signals/figures/samplingReconstructionIllustration.png?raw=1" alt="Illustration of sampling and reconstruction" width="80%"/>
# </center>

# + [markdown] id="Q2CMHZxynuq-"
# ## Continuous-time signal
# A **continuous-time** signal is characterised by
# - **time**: the signal has a value $x(t)$ for every possible time $t$
# - **amplitude**: the signal value $x(t)$ can take on any value from a continuum of numbers (such as the real numbers).
#
# A continuous-time signal is often also referred to as an **analog signal**.
#
# <center>
# <img src="https://github.com/SMC-AAU-CPH/med4-ap-jupyter/blob/main/lecture3_Digital_Audio_Signals/figures/continuousTimeSignal.png?raw=1" alt="Continuous-time signal" width="80%"/>
# </center>
#
# Informally: You draw a continuous-time signal without lifting your pen from the paper.

# + [markdown] id="O1NO96g0nuq_"
# ## Sampling
# - Storing a continuous-time signal on a computer requires an infinite amount of memory!
# - Solution: We only measure the value of a continuous-time signal every $T_\text{s}$ seconds. This is called **sampling**.
# - A very important quantity is
# $$
#     f_\text{s} = 1/T_\text{s}
# $$
# where
#  - $f_\text{s}$ is the **sampling frequency** (measured in Hz) and describes how many times per second the continuous-time signal is sampled
#  - $T_\text{s}$ is the **sampling time** (measured in seconds).
#
# <center>
# <img src="https://github.com/SMC-AAU-CPH/med4-ap-jupyter/blob/main/lecture3_Digital_Audio_Signals/figures/samplingContinuousTimeSignal.png?raw=1" alt="Sampling continuous-time signal" width="80%"/>
# </center>

# + [markdown] id="Omj3iJtpnuq_"
# We can illustrate sampling by a person controlling a contact (see figure below):
# 1. When $T_\text{s}$ seconds has passed, the contact is pushed and released immidiately.
# 2. At that exact time instant, the value of the continuous-time signal $x(T_\text{s})$ is stored on the computer.
# 3. After another $T_\text{s}$ seconds, the contact is again pushed and released immidiately so that $x(2T_\text{s})$ is now stored.
# 4. If we keep pushing/relasing the contact every $T_\text{s}$ seconds, we will after $n$ times store the signal value $x(t_n)$ where
# $$
#     t_n = nT_\text{s} = n/f_\text{s}\ .
# $$
# The scaler $n$ is often referred to as the **sampling index**.
#
# Note that people often write $x(t_n)$ as
# $$
#     x(t_n) = x_n = x[n]\ .
# $$
#
# <center>
# <img src="https://github.com/SMC-AAU-CPH/med4-ap-jupyter/blob/main/lecture3_Digital_Audio_Signals/figures/samplingIllustration.png?raw=1" alt="Illustration of sampling" width="80%"/>
# </center>

# + [markdown] id="rXn9OXwqnurA"
# ## Discrete-time signal
# A **discrete-time** signal is characterised by
# - **time**: the signal only has a value $x_n$ at certain times, i.e., $t_n=nT_\text{s}$ for $n=\cdots,-3,-2,1,0,1,2,3,\cdots$. Therefore, the $x$-axis is often the sampling index $n$ instead of time.
# - **amplitude**: the signal value $x_n$ can take on any value from a continuum of numbers (such as the real numbers).
#
# A discrete-time signal is sometimes also referred to as a **digital signal** (although we will use this term for something slightly different later).
#
# <center>
# <img src="https://github.com/SMC-AAU-CPH/med4-ap-jupyter/blob/main/lecture3_Digital_Audio_Signals/figures/discreteTimeSignal.png?raw=1" alt="Discrete-time signal" width="80%"/>
# </center>
#
# Informally: A discrete-time signal is a series of time-ordered numbers.

# + [markdown] id="vT2QXJRTnurA"
# ## Reconstruction
# If we want to play back a discrete-time signal on, e.g., a loudspeaker, we have to convert the discrete-time signal back into a continuous-time signal.
# - Converting a discrete-time signal $x_n$ into a continuous-time signal $x(t)$ is called **reconstruction**.
# - Reconstruction is performed using two components:
#  - **hold circuit**: holds a value $x_n$ for $T_\text{s}$ seconds. This will create a **staircase** signal.
#  - **post filter**: smooth out the discountinuities in the staircase signal by using a low-pass filter with a cut-off frequency of $f_\text{s}/2$ Hz.
#
# <center>
# <img src="https://github.com/SMC-AAU-CPH/med4-ap-jupyter/blob/main/lecture3_Digital_Audio_Signals/figures/reconstructionIllustration.png?raw=1" alt="Illustration of reconstruction" width="80%"/>
# </center>
#
# ---
# Note that we will talk much more about filtering in the next lectures.

# + [markdown] id="j5ODGo_hnurB"
# ## Summary
# 1. A **continuous-time** signal $x(t)$ can be drawn without lifting the pen from the paper.
# 2. A **discrete-time** signal $x_n = x(t_n)$ is a series of time-ordered numbers.
# 3. **Sampling** converts a $x(t)$ into $x_n$ by measuring the value of $x(t)$ at the times
# $$
#     t_n = nT_\text{s} = n/f_\text{s}
# $$
# where
#  - $n$ is the **sampling index**
#  - $T_\text{s}$ is the **sampling time**
#  - $f_\text{s}=1/T_\text{s}$ is the **sampling frequency**
# 4. **Reconstruction** converts $x_n$ into $x(t)$ by first creating a staircase signal from $x_n$ and then by filtering this staircase signal with a low-pass filter.
#

# + [markdown] id="FsZdzLg6nurB"
# ## Assignment
# Assume that we have a continuous-time signal given by
# $$
#     x(t) = \sin(2\pi f t)
# $$
# where the frequency of the sinusoid is $f=1$ Hz.
# 1. Sketch the signal from $t=-0.5$ s to $t= 2$ s.
#
# We now sample the signal with a sampling frequency of $f_\text{s}=4$ Hz.
# 2. What is the sampling time $T_\text{s}$?
# 3. Sketch the sampled signal $x_n$ (in a new plot with the time index $n$ on the $x$-axis).
# 4. Sketch the staircase signal $x_\text{sc}(t)$ from $x_n$.
# 5. Repeat 2. to 4. with a sampling frequency of $f_\text{s}=1$ Hz.
#

# + [markdown] id="xK3niBqRnurB"
# # Aliasing
# In the next 20 minutes, you will learn
# - How we write a discrete-time sinusoid.
# - What aliasing is.
# - How we can avoid aliasing by selecting the sampling frequency $f_\text{s}$.
# - What an anti-aliasing filter is and why we need it.

# + [markdown] id="sKzKNH7UnurC"
# ### Discrete-time sinusoid
# As we have seen in the first two lectures, a continuous-time sinusoid can be written as
# $$
#     x(t) = A\cos(\Omega t+\psi)
# $$
# where
# - $A\geq 0$ is an amplitude
# - $\Omega=2\pi f$ is a frequency measured in rad/s
# - $\psi$ is the inial phase.
#
# Let us now sample this signal with a sampling frequency of $f_\text{s}$ Hz. We then get the discrete-time sinusoid
# \begin{align}
#     x_n &= x(t_n) = x(n/f_\text{s}) = A\cos(\Omega n/f_\text{s}+\psi) = A\cos((2\pi f/f_\text{s}) n+\psi)\\
#     &= A\cos(\omega n+\psi)
# \end{align}
# where
# - $\omega = \Omega f_\text{s}= 2\pi f/f_\text{s}$ is the **digital frequency** measured in **radians/sample**.
#
# For a discrete-time signal, $\omega = 2\pi$ corresponds to the sampling frequency, and we will also write this frequency as $\omega_\text{s}$.

# + [markdown] id="IWhtAexunurC"
# ## What is Aliasing?
# - **Aliasing** comes from the word **alias**.
# - It refers to that a sinusoidal component of one frequency is 'disguising' itself as a sinusoidal component with another frequency.
#
# As an example, let us try to sample the three continuous-time sinusoids
# \begin{align}
#     x(t) &= \cos(2\pi f t)\\
#     y(t) &= \cos(2\pi (f_\text{s}-f) t)
# \end{align}
# using a sampling frequency of $f_\text{s}$ Hz.

# + [markdown] id="euWqIlfinurC"
# For the first sinusoid, we get that
# $$
#     x_n = \cos(\omega n)\ .
# $$
#
# For the second sinusoid, we get that
# \begin{align}
#     y_n &= \cos((\omega_\text{s}-\omega) n) = \text{Re}\left[\mathrm{e}^{j(\omega_\text{s}-\omega) n}\right] = \text{Re}\left[\mathrm{e}^{j\omega_\text{s} n}\mathrm{e}^{-j\omega n}\right]
# \end{align}
# However, we have that
# $$
#     \mathrm{e}^{j\omega_\text{s}n} = \mathrm{e}^{j2\pi n} = \cos(2\pi n)+j\sin(2\pi n) = 1
# $$
# for all time indices $n$ since $n$ is an integer. This means that
# $$
#     y_n = \text{Re}\left[\mathrm{e}^{-j\omega n}\right] = \cos(-\omega n) = \cos(\omega n)
# $$
# which is exactly the same as $x_n$.

# + [markdown] id="qCPjX0CmnurC"
# **Observation:** Even though the continuous time signals $x(t)$ and $y(t)$ have **different frequencies**, the discrete-time signals $x_n$ and $y_n$ have the **same digital frequency**.
#
# Some consequences:
# - Reconstructing a continuous-time signal from $y_n$ results in $x(t)$ - not $y(t)$.
# - We say that $y(t)$ has been **aliased** when we cannot recover it again after sampling it.
# - A discrete-time sinusoid of digital frequency $\omega=2\pi f/f_\text{s}$, could be a sampled continuous-time sinusoid given by
# $$
#     y(t) = A\cos((\Omega+k2\pi f_\text{s})t + \psi)
# $$
# for any integer $k$.

# + [markdown] id="YCha-e7hnurD"
# <center>
# <img src="https://github.com/SMC-AAU-CPH/med4-ap-jupyter/blob/main/lecture3_Digital_Audio_Signals/figures/aliasingExample.png?raw=1" alt="Example of aliasing" width="80%"/>
# </center>

# + id="b3XZmhAWnurD" colab={"base_uri": "https://localhost:8080/", "height": 392} outputId="e5676b1d-32e5-4fd1-b69f-41930d3163e5"
# %matplotlib inline
import numpy as np
import matplotlib.pyplot as plt

def sinusoid(samplingIndices, digitalFreq):
    '''Compute a cosine'''
    return np.cos(2*np.pi*digitalFreq*samplingIndices)

nData = 100
samplingFreq = 100 # Hz
samplingTime = 1/samplingFreq # s
samplingIndices = np.arange(nData)
time = samplingIndices*samplingTime
freqA = 10 # Hz
freqB = 5 # Hz (samplingFreq-freqA)

# plot the results
plt.figure(figsize=(10,6))
plt.plot(time, sinusoid(samplingIndices,freqA/samplingFreq), linewidth=2, marker='o', label="$x(t)$")
plt.plot(time, sinusoid(samplingIndices,freqB/samplingFreq), linewidth=2, marker='o', label="$y(t)$")
plt.legend()
plt.xlim((time[0],time[nData-1])), plt.ylim((-1.5,1.5))
plt.xlabel('time [s]'), plt.ylabel('Amplitude [.]');

# + [markdown] id="XdrBJIdXnurF"
# ## Nyquist-Shannon sampling theorem
# To avoid aliasing, the maximum frequency $f_\text{max}$ in a continuous-time signal must satisfy that
# $$
#     2f_\text{max} < f_\text{s}
# $$
# where $f_\text{s}$ is the sampling frequency.
#
# We can satisfy the sampling theorem in two ways:
# 1. Select the sampling frequency $f_\text{s}$ high enough
# 2. Pre-filter the continuous-time signal with a low-pass filter (a so-called **anti-aliasing filter**) with a cut-off frequency below $f_\text{s}/2$.

# + [markdown] id="AuVw2Rf9nurF"
# ### Typical sampling frequencies used for recording audio
# | Application | Sampling frequency $f_\text{s}$ |
# |-------------|---------------------------------|
# |CD           | 44100 Hz|
# |Narrowband speech| 8000 Hz|
# |Widebannd speech, VoIP| 16000 Hz|
# |Video recorders| 48000 Hz|
# |DVD-audio and Blu-ray| 96000 and 192000 Hz|

# + [markdown] id="nmxTpqqWnurF"
# ## Anti-aliasing filter
# - Often, we do not know the highest frequency $f_\text{max}$ in our input signal.
# - Instead, we simply filter out all frequency content above $f_\text{s}/2$ to avoid aliasing.
# - This filter is called an **anti-aliasing filter** and is present in all practical sampling blocks.
# <center>
# <img src="https://github.com/SMC-AAU-CPH/med4-ap-jupyter/blob/main/lecture3_Digital_Audio_Signals/figures/ap3SamplingAntiAliasing.png?raw=1" alt="Illustration of filtering and sampling" width="80%"/>
# </center>

# + [markdown] id="_pxFNJGpnurF"
# ### Aliasing also occours in videos and images
# <br />
# <center>
# <a href="http://www.youtube.com/watch?feature=player_embedded&v=ttgLyWFINJI
# " target="_blank"><img src="http://img.youtube.com/vi/ttgLyWFINJI/0.jpg"
# alt="Taylor series" width="480" height="360" border="10" /></a>
# </center>

# + [markdown] id="ZsflIgYunurF"
# <center>
# <img src="https://svi.nl/wikiimg/StFargeaux_kasteel_buiten1_aliased.jpg" alt="Image example of aliasing" width="80%"/>
# </center>

# + [markdown] id="JBKYTMjknurG"
# ## Summary
# 1. A discrete-time sinusoid is written as
# $$
#     x_n = A\cos(\omega n +\psi)
# $$
# where $A$ and $\psi$ have the same meaning as for the continuous-time sinusoid and
# - $\omega = 2\pi f/f_\text{s}$ is the **digital frequency** and measured in rad/sample
# - $f_\text{s}$ is the **sampling frequency** measured in Hz.
# 2. Aliasing refers to when the frequency of a sinusoid is lowered due to undersampling the signal.
# 3. To avoid aliasing, we must satisfy **Nyquist's sampling theorem** stating that
# $$
#     2f_\text{max} < f_\text{s}
# $$
# where $f_\text{max}$ is the maximum frequency in the continuous-time input signal.
# 4. We can limit the maximum frequency of a continuous-time input signal by passing it through an **anti-aliasing filter**. This filter, which is a low-pass filter, ensures that aliasing does not occur.

# + [markdown] id="pEnwlQv7nurG"
# # Binary numbers
# In the next 20 minutes, you will learn
# - What a binary number is
# - What a bit and a byte is
# - How you store data on, e.g., a computer or a CD
# - To get the following slightly geeky joke :)
#
# > There are 10 types of people in this world.
# > Those who understand binary numbers and those who don't!

# + [markdown] id="oNUWi_ttnurG"
# ## The decimal numer systems
# We are used to the decimal number system where we encounter numbers such 3, 42, and 89809.
#
# Let's look at the example
# $$
#     1314\ .
# $$
# We can make the following observations about this decimal number:
# - The number consists of four symbols, each called a **digit**
# - Each digit can be one of ten possible symbols (either 0, 1, 2, 3, 4, 5, 6, 7, 8, or 9).
# - The order of the digits matter. For example, the right-most one in 1314 represents the number of 10s whereas the left-most one represents the number of 1000s. A number system with ordering is called a **positional number system**.

# + [markdown] id="nZ1-2HOwnurG"
# We can rewrite the decimal number 1314 as
# \begin{align}
#     1314 &= 1000 + 300 + 10 + 4\\
#          &= 1\cdot 1000 + 3\cdot 100 + 1\cdot 10 + 4\cdot 1\\
#          &= 1\cdot 10^3 + 3\cdot 10^2 + 1\cdot 10^1 + 4\cdot 10^0\ .
# \end{align}
#
# In general, we can write an $N$ digit decimal number $d_{N-1}d_{N-2}\cdots d_2d_1d_0$ as
# $$
#     d_{N-1}d_{N-2}\cdots d_2d_1d_0 = \sum_{n=0}^{N-1}d_n10^n\ .
# $$
#
# Note that
# - $d_n\in\{0,1,2,3,4,5,6,7,8,9\}$
# - 10 is the number of symbols that $d_n$ can take on and is called the **base** of the decimal number system.

# + [markdown] id="XLNhaSnYnurG"
# Let us now allow for an arbitrary base $b$. Then we can write numbers as
# $$
#     d_{N-1}d_{N-2}\cdots d_2d_1d_0 = \sum_{n=0}^{N-1} d_n b^n
# $$
# where
# - $d_n\in\{0,1,\ldots,b-1\}$
# - $b$ is the base of the number.
#
# For different values of $b$, we get different number systems. Some examples are
# - $b=10$: The **decimal number system** with possible symbols 0,1,2,3,4,5,6,7,8,9
# - $b=2$: The **binary number system** with possible symbols 0,1
# - $b=16$: The **hexadecimal number system** with possible symbols 0,1,2,3,4,5,6,7,8,9, A, B, C, D, E, F

# + [markdown] id="TLh9ssY1nurG"
# ## The binary number system
# A binary number
# - has base 2 and
# - is written only in terms of 0s and 1s.
#
# An example of a binary number is
# $$
#     0110\ 1101_2
# $$
# where the subscript 2 is here only added to make it explicit that $0110\ 1101$ is a binary number.
#
# Note that
# - a 'digit' in a binary number is called a **bit**
# - a collection of 8 bits is called a **byte** with symbol B
# - a computer represents everything (numbers, colours, text, etc.) as binary numbers
#
# Thus, the binary number $0110\ 1101_2$ has 8 bits and 1 byte (or 1 B)

# + [markdown] id="McJjcZ6gnurH"
# ### Converting binary numbers to decimal numbers
# To convert from a binary number to a decimal number, we simple use the expression
# $$
#     d_{N-1}d_{N-2}\cdots d_2d_1d_0 = \sum_{n=0}^{N-1} d_n b^n\ .
# $$
#
# As an example, we get that $1101_2$ converts to
# \begin{align}
#     1101_2 &= 1\cdot 2^3 + 1\cdot 2^2 + 0\cdot 2^1 + 1\cdot 2^0\\
#     &= 1 \cdot 8 + 1 \cdot 4 + 0\cdot 2 + 1\cdot 1\\
#     &= 13_{10}\ .
# \end{align}
#
# Converting from decimal numbers to binary numbers is also possible, but is not covered here.

# + [markdown] id="O9B04BvKnurH"
# ### Adding binary numbers
# You do it exactly as you learned in 2nd grade with decimal numbers. That is,
# - $0_2+0_2 = 0_2$
# - $0_2+1_2 = 1_2$
# - $1_2+1_2 = 0_2$ with $1_2$ in carry
#
# Using these three rules, we obtain
# $$
# \begin{array}[t]{r}
#     0100\ 1001_2 \\
# # + \ 0111\ 1100_2 \\ \hline
#     1100\ 0101_2
# \end{array}
# $$

# + [markdown] id="cQzemcg3nurH"
# ### Example: Representing text using binary numbers
# <center>
# <img src="https://github.com/SMC-AAU-CPH/med4-ap-jupyter/blob/main/lecture3_Digital_Audio_Signals/figures/ascii.png?raw=1" alt="ASCII characters" width="100%"/>
# </center

# + [markdown] id="JJW_D6jbnurH"
# ### Example: Storing data on a disc
# Information is stored by making tiny indentations known as **pits** on a disc.
# - A pit represents a 0
# - The opposite of a pit (called land) represents a 1
# <center>
# <img src="https://github.com/SMC-AAU-CPH/med4-ap-jupyter/blob/main/lecture3_Digital_Audio_Signals/figures/pits.jpg?raw=1" alt="ASCII characters" width="100%"/>
# </center

# + [markdown] id="pGhvTd6WnurI"
# - The binary data is stored along one long spiral on the disc.
#  - **CD**: The spiral is 5.7 km long
#  - **DVD**: The spiral is 12.3 km long
#  - **Blu-ray**: The spiral is 28.4 km long
# - A laser is used for reading the binary data by following this spiral path.
#
# <br />
# <center>
# <img src="https://github.com/SMC-AAU-CPH/med4-ap-jupyter/blob/main/lecture3_Digital_Audio_Signals/figures/spiral.jpg?raw=1" alt="ASCII characters" width="40%"/>
# </center

# + [markdown] id="ZIgxeubdnurI"
# ## Summary
# 1. A binary number
#  - only contains 0s and 1s
#  - consists of bits
# 2. A collection of eight bit is called a **byte**
# 3. Everything (numbers, text, images, video, audio, etc.) is stored and manipulated as binary numbers on a computer
# 4. The following slightly geeky joke is now funny ;)
#
# > There are 10 types of people in this world.
# > Those who understand binary numbers and those who don't!

# + [markdown] id="DWWmkyx8nurI"
# ## Assignment
# 1. Convert the following binary numbers to decimal numbers: $10_2$, $110_2$, and $0101_2$.
# 2. How many different binary numbers could you write with 4 bits?
# 3. How many bits can be stored on a 700 GB harddrive?
# 4. If you have an internet connection with a download speed of 10 Mbit/s, how much time does it then take to download a 100 MB file?
#
# ---
# Bonus info:
# 1. With base $b=2$, a binary number can be written as
# $$
#     d_{N-1}d_{N-2}\cdots d_2d_1d_0 = \sum_{n=0}^{N-1} d_n b^n\ .
# $$
# 2. G means billion ($10^9$), M means million ($10^6$), k means thousand ($10^3$), and B means byte (8 bit)
#

# + [markdown] id="hkM4gsDenurI"
# # Quantisation
# In the next 20 minutes, you will learn
# - What quantisation is and why it is necessary
# - How you will typically do it
# - What signal-to-noise ratio (SNR) and dynamic range is

# + [markdown] id="ldJ5OAxxnurI"
# ## Example: Storing $\pi$ on a computer
# How would you store $\pi$ (or other irrational numbers) on a computer?
# <br />
# <center>
# <img src="https://www.shakespearegeek.com/wp-content/uploads/2017/03/enhanced-buzz-25261-1363280735-6.jpg" alt="Digits of pi" width="70%"/>
# </center

# + [markdown] id="e2ecXWo_nurI"
# - It requires an **infinite** amount of memory to store $\pi$ on a computer.
# - Therefore, we have to store an approximation to $\pi$ with only a **finite** number of digits. Let us call this approximation $p$.
# - The approximation error $e$ can be written as
# $$
#     e = \pi-p\ .
# $$
#
# **Example**: Let $p$ contain only the first two digits of $\pi$ after the comma (i.e., $p=3.14$). Then
# $$
#     e = \pi-p = \pi-3.14 = 0.001592653589\ldots
# $$
#
# We say that we have rounded of (or **quantized**) $\pi$ to its nearest two-digits-after-the-comma representation.

# + [markdown] id="TFjWw8rHnurJ"
# ## The need for quantisation
# Sampling converts a continuous-time signal into a discrete-time signal. That is, we go from an infinite number of time values to a finite number of time values.
#
# <center>
# <img src="https://github.com/SMC-AAU-CPH/med4-ap-jupyter/blob/main/lecture3_Digital_Audio_Signals/figures/ap3SamplingAntiAliasing.png?raw=1" alt="Illustration of sampling" width="80%"/>
# </center>

# + [markdown] id="n-ew1LhonurJ"
# However, we also have to do something about the signal value $x(t_n)=x_n$ for every sampling time, so that we can store this number on the computer using a finite number of digits. This is called **quantisation**.
#
# <center>
# <img src="https://github.com/SMC-AAU-CPH/med4-ap-jupyter/blob/main/lecture3_Digital_Audio_Signals/figures/ap3AdcIllustration.png?raw=1" alt="Illustration of ADC" width="90%"/>
# </center>

# + [markdown] id="3NPkBMMynurJ"
# ## Uniform quantisation
# Assume that we sample the signal value $x_n$ and that
# - the signal value is in the interval $(-\alpha,\alpha)$
# - we have $\beta$ bits available for storing this signal value.
# Note that we can represent $2^\beta$ different values with $\beta$ bits.
#
# We now do the following.
# 1. Divide the interval $(-\alpha,\alpha)$ into $2^\beta$ equally large cells, each of size
# $$
#     \Delta = \frac{\alpha-(-\alpha)}{2^\beta} = \frac{2\alpha}{2^\beta} = \frac{\alpha}{2^{\beta-1}}\ .
# $$
# 2. Round (or **quantise**) the signal value $x_n$ to the value $y_n$ at the nearest cell boundary, i.e.,
# $$
#     y_n = Q(x_n) = \Delta \left\lfloor\frac{x_n}{\Delta}\right\rceil = \Delta \left\lfloor\frac{x_n}{\Delta}+\frac{1}{2}\right\rfloor
# $$
# where $\lfloor\cdot\rceil$ and $\lfloor\cdot\rfloor$ refer to the rounding and flooring operations, respectively.

# + [markdown] id="ux2jISGunurJ"
# ### Example: 3 bit quantisation
# In the figure below, the continuous-time signal (dashed gray) is first sampled (green) and then quantised (orange) using a three bit quantiser. The horisontal dashed red lines mark the quantisation levels. The final bit stream is
# $$
#     100\ 110\ 111\ 111\ 111\ 110\ 110\ 100\ 011\ 010\ 001\ 001\ .
# $$
# <center>
# <img src="https://github.com/SMC-AAU-CPH/med4-ap-jupyter/blob/main/lecture3_Digital_Audio_Signals/figures/ap3ThreeBitQuantisation.png?raw=1" alt="Three bit quantisation" width="70%"/>
# </center>

# + [markdown] id="BxJvOYiZnurJ"
# ## Quantisation error
# The quantisation error $e_n$ is the difference between the signal value $x_n$ and its rounded value $y_n=Q(x_n)$, i.e.,
# $$
#     e_n = x_n-Q(x_n)\ .
# $$
#
# We can rearrange this into
# $$
#     Q(x_n) = x_n+e_n\ .
# $$
# That is, we can think of quantisation as **adding an error** to the signal value $x_n$.
#
# <center>
# <img src="https://github.com/SMC-AAU-CPH/med4-ap-jupyter/blob/main/lecture3_Digital_Audio_Signals/figures/ap3QuantiserBlock.png?raw=1" alt="Quantisation block" width="40%"/>
# </center>

# + [markdown] id="51YsXFDTnurJ"
# A measure of quantisation quality is how big the average power of $e_n$ is compared to the average power of $x_n$. The average power of, e.g., $e_n$ is defined as
# $$
#     P_e = \frac{1}{N}\sum_{n=0}^{N-1} e_n^2\ .
# $$
#
# If we define $P_x$ in a similar way, the signal-to-noise ratio (SNR) is defined as
# $$
#     \text{SNR} = 10\log_{10}\frac{P_x}{P_e}\ ,
# $$
# and it is measured in decibel (dB).

# + [markdown] id="qSP-x-1YnurJ"
# Now, assume that
# - the signal values $x_n$ take on values in $(-\alpha,\alpha)$ equally often (a uniform distribution)
# - the quantisation errors $e_n$ take on values in $(-\Delta/2,\Delta/2)$ equally often (a uniform distribution)
#
# We then get
# \begin{align}
#     P_x &= \frac{(2\alpha)^2}{12} = \frac{\alpha^2}{3}\\
#     P_e &= \frac{\Delta^2}{12} = \frac{1}{12}\left(\frac{\alpha}{2^{\beta-1}}\right)^2\ .
# \end{align}
# These results can be derived by computing the variance of a uniform distribution.

# + [markdown] id="OZDcfSgTnurK"
# Finally, we get the SNR
# \begin{align}
#     \text{SNR} &= 10\log_{10}\frac{P_x}{P_e} = 10\log_{10}\left(\frac{\alpha^2}{3}12\left(\frac{2^{\beta-1}}{\alpha}\right)^2\right)\\
#     &= 10\log_{10}\left(2^{2\beta}\right) = \beta 20 \log_{10} 2 \approx 6\beta\ .
# \end{align}
#
# Thus, for every additional bit, the SNR is improved by approximately 6 dB.

# + [markdown] id="z6_c4UCGnurK"
# ## Dynamic range
# The **dynamic range** is the ratio between the loudest and softest values we can represent using a $\beta$ bit quantiser.
# - **Softest value**: $1$
# - **Loudest value**: $2^\beta$
#
# The dynamic range of a quantiser is thus
# $$
#     \text{DR} = 10\log_{10}\left(\left(\frac{2^\beta}{1}\right)^2\right) = 10\log_{10}\left(2^{2\beta}\right) = \beta 20 \log_{10} 2 \approx 6\beta\ .
# $$
#
# Thus, we get a dynamic range of 96 dB for a 16 bit quantiser (typical CD quality) and 144 dB for a 24 bit quantiser. Note that the dynamic range of the human ear is approximately 120 dB.

# + [markdown] id="Oiil3EBGnurK"
# ## Summary
# 1. A quantiser rounds the signal values to a value on a grid.
# 2. All the points of the grid can be represented using $\beta$ bits which results in $2^\beta$ possible values.
# 3. Quantisation introduces noise into the digital signal. The signal-to-noise ratio (SNR) describes how powerful the signal is compared to this quantisation noise.
# 4. The SNR (and dynamic range) depends on the number of bits used as
# $$
#     \beta20\log_{10} \approx 6\beta\ .
# $$

# + [markdown] id="_0wEyOzW3uj_"
# ## Assignment
# Think of ways for increasing the dynamic range without increasing the number of the bits. *Hint* = Could non-uniform quantisation work?

StarcoderdataJupyterScriptsDedupFiltered
