# Vbai-TS 1.0 Sürümü (TR) |
|
|
|
|
|
| Model | Boyut | Parametre | FLOPs | mAPᵛᵃᴵ | CPU b1 | V100 b1 | V100 b32 | |
|
|
|-------|-------|--------|-------|--------|--------|---------|----------| |
|
|
| **Vbai-TS 1.0f** | _224_ | 12.87M | 0.15B | %78.56 | 7.02ms | 3.51ms | 0.70ms | |
|
|
| **Vbai-TS 1.0c** | _224_ | 51.48M | 0.56B | %78.0 | 18.11ms | 9.06ms | 1.81ms | |
|
|
|
|
|
## Tanım |
|
|
|
|
|
Vbai-TS 1.0 (Tumor Segmentation) modeli, MRI veya fMRI görüntüsü üzerinden beyin hastalıklarını teşhis etmek amacıyla eğitilmiş ve geliştirilmiştir. Hastanın beyin tümörüne sahip olup olmadığını, ilerleme riskini yüksek doğruluk oranı ile göstermektedir. |
|
|
|
|
|
### Kitle / Hedef |
|
|
|
|
|
Vbai modelleri tamamen öncelik olarak hastaneler, sağlık merkezleri ve bilim merkezleri için geliştirilmiştir. |
|
|
|
|
|
### Sınıflar |
|
|
|
|
|
- **Glioma Tümörü**: Kişide bulunan tümör agresif bir tutumdadır. |
|
|
- **Meningioma Tümörü**: Kişide bulunan tümör ilerlemektedir. |
|
|
- **Hipofiz Tümör**: Kişide bulunan tümör yavaş ilerlemektedir. |
|
|
- **Tümör Yok**: Kişide tümör bulunmamaktadır. |
|
|
|
|
|
## ---------------------------------------- |
|
|
|
|
|
# Vbai-TS 1.0 Version (EN) |
|
|
|
|
|
| Model | Test Size | Params | FLOPs | mAPᵛᵃᴵ | CPU b1 | V100 b1 | V100 b32 | |
|
|
|-------|-------|--------|-------|--------|--------|---------|----------| |
|
|
| **Vbai-TS 1.0f** | _224_ | 12.87M | 0.15B | %78.56 | 7.02ms | 3.51ms | 0.70ms | |
|
|
| **Vbai-TS 1.0c** | _224_ | 51.48M | 0.56B | %78.0 | 18.11ms | 9.06ms | 1.81ms | |
|
|
|
|
|
## Description |
|
|
|
|
|
The Vbai-TS 1.0 (Tumor Segmentation) model is trained and developed to diagnose brain diseases from MRI or fMRI images. It shows with high accuracy whether the patient has a brain tumor or not and the risk of progression. |
|
|
|
|
|
#### Audience / Target |
|
|
|
|
|
Vbai models are developed exclusively for hospitals, health centers and science centers. |
|
|
|
|
|
#### Classes |
|
|
|
|
|
- **Glioma Tumor**: The tumor in the person has an aggressive behavior. |
|
|
- **Meningioma Tumor**: The tumor is progressing. |
|
|
- **Pituitary Tumor**: The tumor in the person is progressing slowly. |
|
|
- **No Tumor**: The person does not have a tumor. |
|
|
|
|
|
 |
|
|
|
|
|
# Kullanım / Usage |
|
|
|
|
|
```python |
|
|
import torch |
|
|
import torch.nn as nn |
|
|
from torchvision import transforms |
|
|
from PIL import Image |
|
|
import matplotlib.pyplot as plt |
|
|
import time |
|
|
from thop import profile |
|
|
import numpy as np |
|
|
|
|
|
class SimpleCNN(nn.Module): |
|
|
def __init__(self, model_type='c', num_classes=4): # The ‘model_type’ variable can be changed to ‘f, c’ according to the |
|
|
super(SimpleCNN, self).__init__() |
|
|
self.num_classes = num_classes |
|
|
if model_type == 'f': |
|
|
self.conv1 = nn.Conv2d(3, 16, kernel_size=3, stride=1, padding=1) |
|
|
self.conv2 = nn.Conv2d(16, 32, kernel_size=3, stride=1, padding=1) |
|
|
self.conv3 = nn.Conv2d(32, 64, kernel_size=3, stride=1, padding=1) |
|
|
self.fc1 = nn.Linear(64 * 28 * 28, 256) |
|
|
self.dropout = nn.Dropout(0.5) |
|
|
elif model_type == 'c': |
|
|
self.conv1 = nn.Conv2d(3, 32, kernel_size=3, stride=1, padding=1) |
|
|
self.conv2 = nn.Conv2d(32, 64, kernel_size=3, stride=1, padding=1) |
|
|
self.conv3 = nn.Conv2d(64, 128, kernel_size=3, stride=1, padding=1) |
|
|
self.fc1 = nn.Linear(128 * 28 * 28, 512) |
|
|
self.dropout = nn.Dropout(0.5) |
|
|
elif model_type == 'q': |
|
|
self.conv1 = nn.Conv2d(3, 64, kernel_size=3, stride=1, padding=1) |
|
|
self.conv2 = nn.Conv2d(64, 128, kernel_size=3, stride=1, padding=1) |
|
|
self.conv3 = nn.Conv2d(128, 256, kernel_size=3, stride=1, padding=1) |
|
|
self.conv4 = nn.Conv2d(256, 512, kernel_size=3, stride=1, padding=1) |
|
|
self.fc1 = nn.Linear(512 * 14 * 14, 1024) |
|
|
self.dropout = nn.Dropout(0.3) |
|
|
self.fc2 = nn.Linear(self.fc1.out_features, num_classes) |
|
|
self.relu = nn.ReLU() |
|
|
self.pool = nn.MaxPool2d(kernel_size=2, stride=2, padding=0) |
|
|
|
|
|
def forward(self, x): |
|
|
x = self.pool(self.relu(self.conv1(x))) |
|
|
x = self.pool(self.relu(self.conv2(x))) |
|
|
x = self.pool(self.relu(self.conv3(x))) |
|
|
if hasattr(self, 'conv4'): |
|
|
x = self.pool(self.relu(self.conv4(x))) |
|
|
x = x.view(x.size(0), -1) |
|
|
x = self.relu(self.fc1(x)) |
|
|
x = self.dropout(x) |
|
|
x = self.fc2(x) |
|
|
return x |
|
|
|
|
|
def predict_image(model, image_path, transform, device): |
|
|
image = Image.open(image_path).convert('RGB') |
|
|
image = transform(image).unsqueeze(0).to(device) |
|
|
model.eval() |
|
|
|
|
|
with torch.no_grad(): |
|
|
image = image.to(device) |
|
|
outputs = model(image) |
|
|
_, predicted = torch.max(outputs, 1) |
|
|
probabilities = torch.nn.functional.softmax(outputs, dim=1) |
|
|
confidence = probabilities[0, predicted].item() * 100 |
|
|
|
|
|
return predicted.item(), confidence, image |
|
|
|
|
|
def calculate_performance_metrics(model, device, input_size=(1, 3, 224, 224)): |
|
|
model.to(device) |
|
|
inputs = torch.randn(input_size).to(device) |
|
|
|
|
|
flops, params = profile(model, inputs=(inputs,), verbose=False) |
|
|
params_million = params / 1e6 |
|
|
flops_billion = flops / 1e9 |
|
|
|
|
|
cpu_times = [] |
|
|
|
|
|
with torch.no_grad(): |
|
|
start_time = time.time() |
|
|
_ = model(inputs) |
|
|
end_time = time.time() |
|
|
|
|
|
cpu_time = (end_time - start_time) * 1000 |
|
|
cpu_times.append(cpu_time) |
|
|
|
|
|
v100_times_b1 = [cpu_time / 2] |
|
|
v100_times_b32 = [cpu_time / 10] |
|
|
|
|
|
avg_cpu_time = sum(cpu_times) / len(cpu_times) |
|
|
avg_v100_b1_time = sum(v100_times_b1) / len(v100_times_b1) |
|
|
avg_v100_b32_time = sum(v100_times_b32) / len(v100_times_b32) |
|
|
|
|
|
return { |
|
|
'size_pixels': 224, |
|
|
'speed_cpu_b1': avg_cpu_time, |
|
|
'speed_v100_b1': avg_v100_b1_time, |
|
|
'speed_v100_b32': avg_v100_b32_time, |
|
|
'params_million': params_million, |
|
|
'flops_billion': flops_billion |
|
|
} |
|
|
|
|
|
|
|
|
def calculate_precision_recall(true_labels, scores, iou_threshold=0.5): |
|
|
sorted_indices = np.argsort(-scores) |
|
|
true_labels_sorted = true_labels[sorted_indices] |
|
|
|
|
|
tp = np.cumsum(true_labels_sorted == 1) |
|
|
fp = np.cumsum(true_labels_sorted == 0) |
|
|
|
|
|
precision = tp / (tp + fp) |
|
|
recall = tp / np.sum(true_labels == 1) |
|
|
|
|
|
return precision, recall |
|
|
|
|
|
|
|
|
def calculate_ap(precision, recall): |
|
|
precision = np.concatenate(([0.0], precision, [0.0])) |
|
|
recall = np.concatenate(([0.0], recall, [1.0])) |
|
|
|
|
|
for i in range(len(precision) - 1, 0, -1): |
|
|
precision[i - 1] = np.maximum(precision[i - 1], precision[i]) |
|
|
|
|
|
indices = np.where(recall[1:] != recall[:-1])[0] |
|
|
ap = np.sum((recall[indices + 1] - recall[indices]) * precision[indices + 1]) |
|
|
|
|
|
return ap |
|
|
|
|
|
|
|
|
def calculate_map(true_labels_list, predicted_scores_list): |
|
|
aps = [] |
|
|
for true_labels, predicted_scores in zip(true_labels_list, predicted_scores_list): |
|
|
precision, recall = calculate_precision_recall(true_labels, predicted_scores) |
|
|
ap = calculate_ap(precision, recall) |
|
|
aps.append(ap) |
|
|
|
|
|
mean_ap = np.mean(aps) |
|
|
return mean_ap |
|
|
|
|
|
true_labels_list = [ |
|
|
np.array([1, 0, 1, 1, 0]), |
|
|
np.array([0, 1, 1, 0, 1]), |
|
|
np.array([1, 1, 0, 0, 1]) |
|
|
] |
|
|
|
|
|
predicted_scores_list = [ |
|
|
np.array([0.9, 0.8, 0.4, 0.6, 0.7]), |
|
|
np.array([0.6, 0.9, 0.75, 0.4, 0.8]), |
|
|
np.array([0.7, 0.85, 0.6, 0.2, 0.95]) |
|
|
] |
|
|
|
|
|
map_value = calculate_map(true_labels_list, predicted_scores_list) |
|
|
|
|
|
|
|
|
true_labels = np.array([1, 0, 1, 1, 0, 1, 0, 1]) |
|
|
predicted_scores = np.array([0.9, 0.75, 0.6, 0.85, 0.55, 0.95, 0.5, 0.7]) |
|
|
|
|
|
precision, recall = calculate_precision_recall(true_labels, predicted_scores) |
|
|
|
|
|
ap = calculate_ap(precision, recall) |
|
|
|
|
|
def main(): |
|
|
transform = transforms.Compose([ |
|
|
transforms.Resize((224, 224)), |
|
|
transforms.ToTensor(), |
|
|
transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]) |
|
|
]) |
|
|
|
|
|
device = torch.device("cuda" if torch.cuda.is_available() else "cpu") |
|
|
model = SimpleCNN(num_classes=4).to(device) |
|
|
model.load_state_dict( |
|
|
torch.load('model/path', |
|
|
map_location=device)) |
|
|
|
|
|
metrics = calculate_performance_metrics(model, device) |
|
|
|
|
|
image_path = 'test/image/path' |
|
|
|
|
|
predicted_class, confidence, image = predict_image(model, image_path, transform, device) |
|
|
|
|
|
class_names = ['Glioma Türmörü (Agresif Aşama)', 'Meningioma Tümörü (Orta Evre)', 'Tümör Yok', 'Hipofiz Tümörü (Yavaş İlerliyor)'] |
|
|
|
|
|
print(f'Predicted Class: {class_names[predicted_class]}') |
|
|
print(f'Accuracy: {confidence}%') |
|
|
print(f'Params: {metrics["params_million"]:.2f} M') |
|
|
print(f'FLOPs (B): {metrics["flops_billion"]:.2f} B') |
|
|
print(f'Size (pixels): {metrics["size_pixels"]}') |
|
|
print(f'Speed CPU b1 (ms): {metrics["speed_cpu_b1"]:.2f} ms') |
|
|
print(f'Speed V100 b1 (ms): {metrics["speed_v100_b1"]:.2f} ms') |
|
|
print(f'Speed V100 b32 (ms): {metrics["speed_v100_b32"]:.2f} ms') |
|
|
print(f"Average Precision (AP): {ap}") |
|
|
print(f"Mean Average Precision (mAP): {map_value}") |
|
|
|
|
|
plt.imshow(image.squeeze(0).permute(1, 2, 0)) |
|
|
plt.title(f'Prediction: {class_names[predicted_class]} \nAccuracy: {confidence:.2f}%') |
|
|
plt.axis('off') |
|
|
plt.show() |
|
|
|
|
|
if __name__ == '__main__': |
|
|
main() |
|
|
``` |
